In response to a recent comment regarding my Connect to Cisco 851 with Cisco VPN Client post from a couple years back the following code is a revision that includes split tunneling support and updated comments within the code. If the VPN client appears to connect successfully but you are unable to access network devices then the following tips may help.

• Check, review the access-lists paying special attention to the one that corresponds to your route map. The first line of your route-map access-list should be a deny statement relating to the designated vpn subnet. This line sends VPN client sourced traffic back to your connecting machine.
• Ensure the name of your route-map is referenced correctly in your outside interface ip nat statement
• Confirm ip nat inside and ip nat outside commands are on the appropriate interfaces

The code below is from a working production environment.

version 12.4
no service pad
service timestamps debug datetime msec
service timestamps log datetime msec
no service password-encryption
!
hostname DEMO851w
!
boot-start-marker
boot-end-marker
!
logging buffered 51200 warnings
!
aaa new-model
!
!
aaa authentication login demousers local
aaa authorization network demogroup local
!
aaa session-id common
!
resource policy
!
clock timezone Hawaii -10
ip subnet-zero
!
!
ip cef
ip inspect name DEFAULT100 cuseeme
ip inspect name DEFAULT100 ftp
ip inspect name DEFAULT100 h323
ip inspect name DEFAULT100 icmp
ip inspect name DEFAULT100 rcmd
ip inspect name DEFAULT100 realaudio
ip inspect name DEFAULT100 rtsp
ip inspect name DEFAULT100 esmtp <consider removing this line for Exchange 2007 compatibility>
ip inspect name DEFAULT100 sqlnet
ip inspect name DEFAULT100 streamworks
ip inspect name DEFAULT100 tftp
ip inspect name DEFAULT100 tcp
ip inspect name DEFAULT100 udp
ip inspect name DEFAULT100 vdolive
ip tcp synwait-time 10
no ip bootp server
no ip domain lookup
ip domain name domain.local
ip name-server <internal dns>
!
username sysadmin privilege 15 secret 5 <password hash>
<add more vpn users here>
!
crypto isakmp policy 1
 encr 3des
 authentication pre-share
 group 2
crypto isakmp client configuration address-pool local dynpool
!
crypto isakmp client configuration group demogroup <VPN client Group Authentication name>
 key <group passphrase for vpn client>
 dns <internal dns>
 domain domain.local
 pool dynpool
 acl 105
!
crypto ipsec transform-set transform-1 esp-3des esp-sha-hmac
!
crypto dynamic-map dynmap 1
 set transform-set transform-1
 reverse-route
!
crypto map dynmap client authentication list demousers
crypto map dynmap isakmp authorization list demogroup
crypto map dynmap client configuration address respond
crypto map dynmap 1 ipsec-isakmp dynamic dynmap
!
bridge irb
!
interface FastEthernet0
!
interface FastEthernet1
!
interface FastEthernet2
!
interface FastEthernet3
!
interface FastEthernet4
 description ** WAN **
 ip address <external ip> 255.255.255.x
 ip access-group 101 in
 ip verify unicast reverse-path
 no ip redirects
 no ip unreachables
 no ip proxy-arp
 ip inspect DEFAULT100 out
 ip nat outside
 ip virtual-reassembly
 ip route-cache flow
 duplex auto
 speed auto
 crypto map dynmap
!
interface Dot11Radio0
 no ip address
 !
 encryption vlan 1 mode ciphers tkip
 !
 ssid AP851G
    vlan 1
    authentication open
    authentication key-management wpa
    guest-mode
    wpa-psk ascii 0 <password>
 !
 speed basic-1.0 basic-2.0 basic-5.5 6.0 9.0 basic-11.0 12.0 18.0 24.0 36.0 48.0
 54.0
 station-role root
!
interface Dot11Radio0.1
 encapsulation dot1Q 1 native
 no snmp trap link-status
 no cdp enable
 bridge-group 1
 bridge-group 1 subscriber-loop-control
 bridge-group 1 spanning-disabled
 bridge-group 1 block-unknown-source
 no bridge-group 1 source-learning
 no bridge-group 1 unicast-flooding
!
interface Vlan1
 description
 no ip address
 ip tcp adjust-mss 1452
 bridge-group 1
!
interface BVI1
 description
 ip address 192.168.1.1 255.255.255.0
 ip nat inside
 ip virtual-reassembly
 ip tcp adjust-mss 1412
!
ip local pool dynpool 192.168.15.1 192.168.15.5
ip classless
ip route 0.0.0.0 0.0.0.0 <isp gateway>
!
ip http server
ip http authentication local
ip http secure-server
ip http timeout-policy idle 60 life 86400 requests 10000
ip nat inside source route-map nonat interface FastEthernet4 overload
ip nat inside source static tcp <internal server> 25 <external ip> 25 extendable
ip nat inside source static tcp <internal server> 80 <external ip> 80 extendable
ip nat inside source static tcp <internal server> 443 <external ip> 443 extendable
!
access-list 1 permit 192.168.0.0 0.0.255.255
access-list 101 remark ** Permit Inbound IPSEC Traffic & Split Tunnel **
access-list 101 permit ip host 192.168.15.1 192.168.1.0 0.0.0.255
access-list 101 permit ip host 192.168.15.2 192.168.1.0 0.0.0.255
access-list 101 permit ip host 192.168.15.3 192.168.1.0 0.0.0.255
access-list 101 permit ip host 192.168.15.4 192.168.1.0 0.0.0.255
access-list 101 permit ip host 192.168.15.5 192.168.1.0 0.0.0.255
access-list 101 permit udp any host <external ip> eq non500-isakmp
access-list 101 permit udp any host <external ip>
access-list 101 permit esp any host <external ip>
access-list 101 permit ahp any host <external ip>
access-list 101 remark ** Block Telnet **
access-list 101 deny   tcp any any eq telnet
access-list 101 permit tcp any any established
access-list 101 remark ** Deny netbios from the internet **
access-list 101 deny   tcp any any eq 139 log
access-list 101 deny   udp any any eq netbios-ns log
access-list 101 deny   udp any any eq netbios-dgm log
access-list 101 deny   udp any any eq netbios-ss log
access-list 101 remark ** Permit Exchange Related Traffic **
access-list 101 permit tcp any host <external ip> eq smtp
access-list 101 permit tcp any host <external ip> eq www
access-list 101 permit tcp any host <external ip> eq 443
access-list 101 permit udp any host <external ip> eq ntp
access-list 101 deny   ip any host <external ip>
access-list 101 remark ** Permit all other traffic **
access-list 101 permit tcp any any
access-list 101 permit udp any any
access-list 101 permit ip any any
access-list 105 remark ** VPN Traffic **
access-list 105 permit ip 192.168.1.0 0.0.0.255 any
access-list 110 deny   ip 192.168.1.0 0.0.0.255 192.168.15.0 0.0.0.255
access-list 110 permit ip 192.168.1.0 0.0.0.255 any
snmp-server community public RO
no cdp run
route-map nonat permit 10
 match ip address 110
!
control-plane
!
bridge 1 protocol ieee
bridge 1 route ip
!
line con 0
 no modem enable
line aux 0
line vty 0 4
 privilege level 15
 transport input telnet ssh
!
scheduler max-task-time 5000
scheduler allocate 4000 1000
scheduler interval 500
ntp clock-period 17175022
ntp server 140.31.199.8 prefer
end
DEMO851w#

Comments questions welcomed.
